epoxy glass cloth/G10 laminated sheet/epoxy woven glass from China manufacturer

epoxy glass cloth/G10 laminated sheet/epoxy woven glass

Price:	1.0~10000.0 USD
Payment Terms:	T/T,L/C
Special Groups:	Electrical /Electronics/Insulation (17)
Place of Origin:	, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: G10/FR4/G11/FR5

Production Capacity: 100tons/month

Delivery Date: 7-15 days

Means of Transport: Ocean

Packing: 500-1000kgs Per Pallet or a...

Electrical / Electronics/: Insulation

Epoxy Glass Fabric Laminated sheets (also known as: Epoxy glass cloth laminated sheet, G10/FR4/G11/FR5 glass fibre epoxy laminate, epoxy glass lamina

Epoxy Glass Fabric Laminated sheets (also known as: Epoxy glass cloth laminated sheet, G10/FR4/G11/FR5 glass fibre epoxy laminate, epoxy glass laminate, epoxy glass fiber laminate, glass reinforced epoxy, epoxy fiberglass laminate, FR4 G10 unclad laminate, FR4 garolite, G10 FR4 rigid laminate)

Descriptions:
These grades are composed of glass woven fabric base impregnated with an epoxy resin binder. They have extremely high mechanical strength and electrical strength. Good dielectric properties under dry and humid conditions. Excellent rigidity and dimensional stability.

Applications:
Widely used as insulating structural parts in electrical & mechanical equipments, such as generators, motors, transformer, PC boards, etc.

Specifications:
1) Grade: G10/FR4/G11/FR5
2) Color: Light Green; Yellow; Black
3) Thickness range: 0.1mm to 180mm.
4) Sheet Size: 915*1220mm; 1020*1220mm; 1020*2040mm; 1220*2470mm
5) Minimum Order: 500 kgs in a lot
6) Packing: 500~1, 000kgs/pallet or as required
